The CNF-600WOM 600W CO2 Laser Power Supply is designed for a single discharge/high impedance laser tube. The output capacitance of the power supply is tiny (almost output cable capacitance only), so the tube current is very stable from the minimum current to the maximum tube current.
- Ultra low output capacitance
- Suitable for a single discharge/high impedance laser tube
- High power up to 600W
- Ballastless Operation
- No Maintenance Required
Key Features
- Ultra low output capacitance
- Very stable operation for a single discharge with high impedance tubes
- Output Voltage up to 45KV
- Compact 600W Water Cooled CO2 Laser Power Supply
- Ballastless Operation
- No Maintenance Required
Specifications
- Output Power: 600W
- Striking Voltage: 45KV
- Operating Voltage: 4KV to 40KV
- Output Configuration: P: Single Output
- Operating Current: Total 40mA
- Operating Mode: CW & PULSE
- Pulse Rep. Rate: DC to 2KHz
- Pulse Width: 100µs to DC
- AC Input Voltage: 80-120V, or 180-240V
- Efficiency: Greater than 88% (Maximum Efficiency)
- Regulation: Less than 2%
- Protection Mode: H.V. Over current, H.V. Over voltage, IGBT Over current, Over Temperature
- Control Signal: 0-5V Ground referenced signals: LASER, READY, POWER, FAULT, RESET, GND, +5V. Refer to control signals for details
- Options: H.V Current/Voltage readout
- Dimension: 5.30″H x 4.70″W x 7.40″L inch (excluding flanges)
- Weight: 9.6 lb
- Cooling: Water Cooled
